Description
• A pressure of 16 mbar (water temperature of 12°C) is achievable with a water supply pressure from 3 to 6 bar
• Detachable vacuum connection – accepts 6-9mm bore tubing
• High suction capacity with a flow rate of approx. 400 litres/h of air (at 1 atm and water supply pressure of 3.5 bar at 12°C)
• Integrated non-return valve increases safety
• Suitable for most laboratory water pressures
• Supplied with water inlet hose nipple and R 3/4” threaded tap connectors, with R 1/2” reduction adapter
• Very low water consumption: 190 litre/h at 3.5 bar water supply pressure
• Water inlet hose nipple accepts 10-12mm bore tubing
INFO : Jubilee clips are recommended to fix tubing into position.
INFO :- Polypropylene, PP
• Autoclavable at 121ºC
• Good to excellent chemical resistance
• Resistant to fatigue making it tough
• Temperature range -20 to +135ºC
• Translucent rigid polymer
• Typically used for beakers, bottles and cylinders
